HIS HD 4850 IceQ 4 Turbo 512MB (256bit) GDDR3 PCIe
  • H485QT512P_Set_1600.jpg
  • HD4850_iceq4_uv_1600.jpg
  • HD4850_IceQ2_4_1600
  • HD4850_IceQ2_5_1600
  • HD4850_IceQ4_v1_1600
  • HD4830_IceQ4_v3_1600
  • HD4830_IceQ4_v2_1600
  • HD4850_Q4_3DBox_v2_T
  • HD4850Q_Accessories
  • HIS_bundling_2_u_800
Product Code H485QT512P
EAN Code 4895139001013
Cooler IceQ 4
GPU 4850
Core Clock 650 MHz
Memory Clock 2000 MHz
Memory Size 512 MB
Memory Type GDDR3
Memory Interface 256 bit
Interface PCI Express x16 (PCI Express 2.0)
Card Dimension 12.5 x 24.6 x 4 cm
Box Dimension 34.5 x 21.5 x 5.5 cm
Box Weight 1.23 kg
Availability Available

  • Windows 7 Compatibility
  • ATI Premium Graphics™
  • ATI Stream Technology™
  • ATI CrossfireX™
  • DirectX 10.1
  • IceQ 4
  • UV Sensitive
  • PCI Express 2.0
  • 1080p
  • HDMI
  • HDTV
  • Dual Monitor
  • Unified Video Decoder 2
  • Gaming
  • Dual DVI
  • TV-Out
  • Retail Pack

Product Advantage

HIS IceQ 4 is the 4th generation of IceQ cooling technology, which is endorsed by the media worldwide. Thanks to the newly designed double-slot fans and dual heatpipes, HIS IceQ 4 effectively dissipate the heat from the GPU, thus enabling it for high levels of performance. It cools down the GPU temperature dramatically when compare with the reference cooler, allow you to maximize your overclocking potential. What's more? The ultra silent and durable fan delivers ultra-quiet and stable gaming environment for enthusiast gamer.


Heat transfers rapidly out of GPU and reduces temperature faster.

Cool down the droom to overclock and run chip faster; provides more headroom to overclock and run faster.

Operates with lower noise level than original cooler.
  1. Efficient transfer of heat outside of computer case
    Cool air is drawn from both sides of the fan and hot air is forced out of the computer case. This ensures effective cooling when there is another card in front blocking the fan inlet.
  2. Crossfire Advantage
    For CrossFire setup, the fan ensures effective cooling with another card blocking at front.
  3. Silent and durable fan
    Significantly reduce noise level and extend service life
  4. Dual Heatpipe
    Heat is rapidly transferred from the core area reducing the GPU temperature.
  5. UV Sensitive
    IceQ4 will glow under UV light.




Faster - Heat transfers rapidly out of GPU and reduces temperature faster

In order to improve the power capacity, we have changed from simple extrusion heatsink to stacked fins with bigger surface area to improve the heat transfer efficiency significantly. Thicker spreader and heatpipes are also used to allow a more even heat distribution among the fins. Spreader is the metal base of the heatsink.

" And the winner is HIS HD4850 IceQ4 Turbo. Among the other cards, only IceQ4 cooling system manages to lower the heat of 4850 GPU to a level which we have been expecting for a time. HIS has the best solution for cooling and power consumption with " - Darkhardware.com

" The cooling effect is much better than the reference cooler, allow you to maximize your overclocking potential. " - PC Market


Cooler - Efficient transfer of heat outside of computer case:

Cool air is drawn from both sides of the fan and hot air is forced out of the computer case. This ensures effective cooling when there is another card in front blocking the fan inlet, such as in CrossFire setup. Memory and GPU heatsinks are completely separated, preventing any heat transfer from GPU to memory. Memory heatsink is actively cooled by air stream from main cooler.

Cooling Performance - IceQ 4 vs Single Slot Cooler

By expelling the hot air, IceQ 4 removes all the heat generated by the GPU out of the computer chassis, prevents the hot air from accumulating inside and enhancing the overall stability. The more crowded the chassis, the greater will be the impact. Following charts illustrate the impact on cooler performance:

Cool air is drawn from both sides of the fan and hot air is forced out of the computer case. This ensures effective cooling when there is another card in front blocking the fan inlet, such as in CrossFire setup.

The demonstration shows that the IceQ 4 does outperform the 3rd party cooler in closed environment. The improvement in cooling effect is even more noticeable when a board is placed in front of the graphics card, such as in Crossfire setup.


Quieter - Significantly reduce noise level and extend service life

" HIS has done an excellent job on the 4850IceQ4 - besides the quality of the card the fabulous cooler ICeQ4 is efficient and silent and the factory overclock offers a fantastic performance. " - ForumPC (Brazil)

" With the ICEQ4 cooler you can expect roughly 40-41 dB at peak GPU usage (fan RPM will be higher when GPU is hotter " - Guru3D

" HIS by tooling up their IceQ4 Cooler not only made their card silent but were able to do that and make the card operate some 20 degrees cooler than others. " - Overclockercafe.com


" As stated, the plastic cooler is UV reflective, throw in a 5 USD UV cold-cathode and you can get that nice dark ocean blue thing going on. The ICEQ4 cooler is both silent and offers much better than reference cooling performance. Next to that, it looks quite nice as well, throw in a little cold-cathode UV light and the thing will shine up like it's radiated .. lovely to look at. " - From Guru3D.com


HIS Product Advantage
  • Innovative IceQ 4 Cooling technology
  • Faster : Heat transfers rapidly out of GPU and reduces temperature faster.
  • Cooler: Cool down the droom to overclock and run chip faster; provides more headroom to overclock and run faster.
  • Quieter: Operates with lower noise level than original cooler.
  • UV Sensitive: Enhancing the gamers' UV light case
  • Crossfire Advantage: Ensures effective cooling when there is another card in front blocking the fan inlet, such as in CrossFire setup.
Chipset Features
  • Powered by Radeon® HD 4850 GPU
  • 956 million transistors on 55nm fabrication process
  • 800 stream processing units
  • DirectX® 10.1
  • 24x custom filter anti-aliasing (CFAA) and high performance anisotropic filtering
  • ATI CrossFireXTM multi-GPU support for highly scalable performance
  • Use up to four discrete cards with an AMD 790FX based motherboard
  • Built-in HDMI with 7.1 surround sound support
    • The HIS DVI to HDMI Adapter for ATI 4000/ 3000 series (Product Code: HHDMI4071) is required to fully utilize the audio through HDMI features
  • PCI Express® 2.0 support
SOFTWARE BUNDLED
  • Driver CD
CABLE/ADAPTOR BUNDLED
  • ATI CrossFireXTM Bridge Interconnect
  • DVI to HDMI adapter
  • DVI to VGA adapter
  • S-video to composite Adapter
  • Power Cable 2x 4pin in, 6 pin out
  • HIS Multi-purpose Screw Driver Pen (Screw Driver, LED Light, Spirit Level)

Model Name HIS HD 4850 IceQ 4 Turbo (Full HD 1080p) HDMI 512MB (256bit) GDDR3 Dual DL-DVI & TV (HDCP) PCIe (RoH
Chipset Radeon HD 4800 PCIe Series
ASIC RadeonTM HD 4850 GPU
Pixel Pipelines 800 stream processing units* (Unified)
Vertex Engines 800 stream processing units* (Unified)
Manu. Process (Micron) 55nm
Transistor 956 million
Memory Size (MB) 512
Memory Type GDDR3
RAMDAC (MHz) 400
Engine CLK (MHz) 650
Memory CLK (MHz) 2000
Memory Interface (bit) 256
Power Supply Requirement 450 Watt or greater power supply with 75 Watt 6-pin PCI Express® power connector recommended (550 Watt and two 6-pin connectors for ATI CrossFireX™ technology in dual mode)
Max. Resolution Two x 2560*1600 (Dual dual-link)
Bus Interface PCI Express x16
VGA No
2nd VGA No
DVI Yes
2nd DVI Yes
TV-out No
HDTV (YPrPb component output) No
Video-in No
TV Tuner No
FM Tuner No

ATI Radeon™ HD 4850 System Requirements
  • PCI Express® based PC is required with one X16 lane graphics slot available on the motherboard
  • 450 Watt or greater power supply with 75 Watt 6-pin PCI Express® power connector recommended (550 Watt and two 6-pin connectors for ATI CrossFireX™ technology in dual mode)
  • Certified power supplies are recommended. Refer to http://ati.amd.com/certifiedPSU for a list of Certified products
  • Minimum 1GB of system memory
  • Installation software requires CD-ROM drive
  • DVD playback requires DVD drive
  • Blu-ray™ playback requires Blu-ray drive
  • For a complete ATI CrossFireX™ system, a second ATI Radeon™ HD 4850 graphics card, an ATI CrossFireX Ready motherboard and one ATI CrossFireX Bridge Interconnect cable per graphics card are required

For more information, please visit the following link:
http://ati.amd.com/products/radeonhd4800/specs1.html





HIS IceQ 4 Cooling Technology - Pushing the HD4850 to its limit!

HIS IceQ 4 is the 4th generation of IceQ cooling technology, which is endorsed by the media worldwide. Thanks to the newly designed double-slot fans and heatsink, IceQ 4 effectively dissipate the heat from the GPU, thus enabling it for high levels of performance. The newly designed heat-pipes layout shows its strength in effectively transfer heat from the core are and reducing the GPU temperature. Larger heatsink surface areas are implemented to maximize heat dissipation. HIS IceQ 4 cool down the GPU temperature dramatically when compare with the reference cooler, allow you to maximize your overclocking potential. Cooling capacity is increased by up to 20% in gaming mode.

Efficient transfer of heat outside of computer case:Cool air is drawn from both sides of the fan and hot air is forced out of the computer case. It ensures effective cooling when there is another card in front blocking the fan inlet such as in CrossFire setup. (Other brands' cooler leaves the heat generated from GPU inside the case so the temperature inside the case will be increased leading to higher GPU temperature affecting the stability of the graphic card.)

Dual-slot cooling design:Ensure you can conveniently connect the CrossFire cable to run a CrossFire setup. Other brands' cooler which is greater than Dual-slot cannot run CrossFire Setup in some motherboards.

Silent and durable fan: Significantly reduce noise level and extend service life.

Isolated heatsinks:Memory and GPU heatsinks are completely separated, preventing any heat transfer from GPU to memory. Memory heatsink is actively cooled by air stream from main cooler.

Redefine HD Gaming

The ATI Radeon HD 4800 Series GPUs deliver a cinematic gaming experience with unprecedented performance. The powerful new TeraScale graphics will propel you deep into your gameplay with seamless frame rates and high resolutions. Enhanced anti-aliasing (AA) and anisotropic filtering create striking graphics with unparalleled realism so you can max out the settings of the most demanding next-generation games or revitalize your favorite titles. Play today while preparing for tomorrow with tessellation, support for DirectX® 10.1 and scalable ATI CrossFireXTM technology.

ATI AvivoTM HD Technology

ATI AvivoTM HD is the advanced image and video processing and display technology found in ATI RadeonTM HD GPUs and ATI TheaterTM video capture processors. Specifically designed for HDTV and HD video enthusiasts, ATI Avivo HD provides brilliant colors, sharp images, smooth playback of Blu-rayTM* and HD video content, HDMI with built-in multi-channel digital audio, and on some GPUs, Unified Video Decoding (UVD). UVD is designed to enable a cool and quiet media PC with low CPU power requirements and playback of HD 1080p content. HD Monitor is required for full 1080p enjoyment.

HDMI Video and Audio

A system with an ATI RadeonTM HD 4800 Series graphics card can help enhance the HD entertainment experience by providing a seamless connection to an HDTV or home theater system. With built-in 7.1 surround sound audio (AC3 / DTS ), the new GPUs and graphics cards support single cable connection directly to a compatible HDTV, projector or receiver. This single cable carries both the HD video and 8 channel audio for a clean, high definition connection. Some graphics cards will be equipped with an HDMI connector, while others will output the HDMI signal using a special ATI Radeon DVI-I to HDMI adapter. These options give consumers more options and flexibility when connecting their PCs to monitors or home theaters for maximum enjoyment of HD content. The new GPU also supports xvYCC color which can display a wider range of color when connected to capable HDTVs.

* The HIS DVI to HDMI Adapter for ATI 4000/ 3000 series (Product Code: HHDMI4071) is required to fully utilize the audio through HDMI features

Microsoft® DirectX® 10.1 support

ATI RadeonTM HD 4800 series GPUs offer full support for the new DirectX® 10 and DirectX® 10.1 API (Application Program Interface) from Microsoft; ready to meet the demanding needs of new, next generation games. DirectX 10 is the first totally new DirectX in the last 4 years and brings important graphics innovations that can be used by game developers for the next generation of games. DirectX 10 introduces crisp, never-beforeseen detail-rich images, visual effects and game dynamics capable of accurately simulating the real world. No matter which ATI RadeonTM HD 4800 Series GPU you choose, you can be assured that games will look as good as the developer intended!

ATI CrossFireXTM Technology

ATI CrossFireXTM multi-GPU technology takes your gaming experience to the next level with superb scalability, performance and compatibility. The technology combines the awe-inspiring capabilities of multiple ATI RadeonTM graphics cards and an ATI CrossFireX ready motherboard to meet the hard-core demands of your alternate reality. New ATI RadeonTM HD graphics cards are designed with an internal ATI CrossFireTM Bridge Interconnect system to simplify installation.

Microsoft® Windows Vista®

ATI RadeonTM HD 4800 series graphics cards provide support for the Microsoft® Windows Vista® operating system and take advantage of the Windows AeroTM graphical interface. You will be amazed by the dazzling 3D visual effects and have peace of mind that the ATI CatalystTM software and drivers are designed and thoroughly tested to ensure full compatibility and stability to help keep you up and running. All these new technologies and features make the ATI Radeon HD 4800 series of GPUs the ideal solution for ultimate HD gaming and HD video entertainment with the Windows Vista OS
