HIS IceQ 4 is the 4th generation of IceQ cooling technology, which is endorsed by the media worldwide. Thanks to the newly designed double-slot fans and dual heatpipes, HIS IceQ 4 effectively dissipate the heat from the GPU, thus enabling it for high levels of performance. It cools down the GPU temperature dramatically when compare with the reference cooler, allow you to maximize your overclocking potential. What's more? The ultra silent and durable fan delivers ultra-quiet and stable gaming environment for enthusiast gamer.
Heat transfers rapidly out of GPU and reduces temperature faster.
Cool down the droom to overclock and run chip faster; provides more headroom to overclock and run faster.
Operates with lower noise level than original cooler.
- Efficient transfer of heat outside of computer case
Cool air is drawn from both sides of the fan and hot air is forced out of the computer case. This ensures effective cooling when there is another card in front blocking the fan inlet.
- Crossfire Advantage
For CrossFire setup, the fan ensures effective cooling with another card blocking at front.
- Silent and durable fan
Significantly reduce noise level and extend service life
- Dual Heatpipe
Heat is rapidly transferred from the core area reducing the GPU temperature.
- UV Sensitive
IceQ4 will glow under UV light.
Faster - Heat transfers rapidly out of GPU and reduces temperature faster
In order to improve the power capacity, we have changed from simple extrusion heatsink to stacked fins with bigger surface area to improve the heat transfer efficiency significantly. Thicker spreader and heatpipes are also used to allow a more even heat distribution among the fins. Spreader is the metal base of the heatsink.
" And the winner is HIS HD4850 IceQ4 Turbo. Among the other cards, only IceQ4 cooling system manages to lower the heat of 4850 GPU to a level which we have been expecting for a time. HIS has the best solution for cooling and power consumption with " - Darkhardware.com
" The cooling effect is much better than the reference cooler, allow you to maximize your overclocking potential. " - PC Market
Cooler - Efficient transfer of heat outside of computer case:
Cool air is drawn from both sides of the fan and hot air is forced out of the computer case. This ensures effective cooling when there is another card in front blocking the fan inlet, such as in CrossFire setup. Memory and GPU heatsinks are completely separated, preventing any heat transfer from GPU to memory. Memory heatsink is actively cooled by air stream from main cooler.
Cooling Performance - IceQ 4 vs Single Slot Cooler
By expelling the hot air, IceQ 4 removes all the heat generated by the GPU out of the computer chassis, prevents the hot air from accumulating inside and enhancing the overall stability. The more crowded the chassis, the greater will be the impact. Following charts illustrate the impact on cooler performance:
Cool air is drawn from both sides of the fan and hot air is forced out of the computer case. This ensures effective cooling when there is another card in front blocking the fan inlet, such as in CrossFire setup.
The demonstration shows that the IceQ 4 does outperform the 3rd party cooler in closed environment. The improvement in cooling effect is even more noticeable when a board is placed in front of the graphics card, such as in Crossfire setup.
Quieter - Significantly reduce noise level and extend service life
" HIS has done an excellent job on the 4850IceQ4 - besides the quality of the card the fabulous cooler ICeQ4 is efficient and silent and the factory overclock offers a fantastic performance. " - ForumPC (Brazil)
" With the ICEQ4 cooler you can expect roughly 40-41 dB at peak GPU usage (fan RPM will be higher when GPU is hotter " - Guru3D
" HIS by tooling up their IceQ4 Cooler not only made their card silent but were able to do that and make the card operate some 20 degrees cooler than others. " - Overclockercafe.com
HIS IceQ is also UV sensitive, enhancing the gamers' UV light case
" As stated, the plastic cooler is UV reflective, throw in a 5 USD UV cold-cathode and you can get that nice dark ocean blue thing going on. The ICEQ4 cooler is both silent and offers much better than reference cooling performance. Next to that, it looks quite nice as well, throw in a little cold-cathode UV light and the thing will shine up like it's radiated .. lovely to look at. " - From Guru3D.com
HIS Product Advantage
- Innovative IceQ 4 Cooling technology
- Faster : Heat transfers rapidly out of GPU and reduces temperature faster.
- Cooler: Cool down the droom to overclock and run chip faster; provides more headroom to overclock and run faster.
- Quieter: Operates with lower noise level than original cooler.
- UV Sensitive: Enhancing the gamers' UV light case
- Crossfire Advantage: Ensures effective cooling when there is another card in front blocking the fan inlet, such as in CrossFire setup.
- Powered by Radeon® HD 4850 GPU
- 956 million transistors on 55nm fabrication process
- 800 stream processing units
- DirectX® 10.1
- 24x custom filter anti-aliasing (CFAA) and high performance anisotropic filtering
- ATI CrossFireXTM multi-GPU support for highly scalable performance
- Use up to four discrete cards with an AMD 790FX based motherboard
- Built-in Native HDMI with 7.1 surround sound support
- PCI Express® 2.0 support
What's in the box
|Model Name||HIS HD 4850 IceQ 4 (Full HD 1080p) Native HDMI 1GB (256bit) GDDR3 Dual Link-DVI / VGA / HDMI (HDCP) PCIe (RoHS)
|Chipset||Radeon HD 4800 PCIe Series|
|ASIC||RadeonTM HD 4800 GPU|
|Pixel Pipelines||800 stream processing units* (Unified)|
|Vertex Engines||800 stream processing units* (Unified)|
|Manu. Process (Micron)||55nm|
|Memory Size (MB)||1024|
|Engine CLK (MHz)||625|
|Memory CLK (MHz)||1986|
|Memory Interface (bit)||256|
|Power Supply Requirement||450 Watt or greater power supply with 75 Watt 6-pin PCI Express® power connector recommended (550 Watt and two 6-pin connectors for ATI CrossFireX™ technology in dual mode)|
|Max. Resolution||Two x 2560*1600 (Dual dual-link)|
|Bus Interface||PCI Express x16|
- ATI Radeon™ HD 4850 System Requirements
- PCI Express® based PC is required with one X16 lane graphics slot available on the motherboard
- 450 Watt or greater power supply with 75 Watt 6-pin PCI Express® power connector recommended (550 Watt and two 6-pin connectors for ATI CrossFireX™ technology in dual mode)
- Certified power supplies are recommended. Refer to http://ati.amd.com/certifiedPSU for a list of Certified products
- Minimum 1GB of system memory
- Installation software requires CD-ROM drive
- DVD playback requires DVD drive
- Blu-ray™ playback requires Blu-ray drive
- For a complete ATI CrossFireX™ system, a second ATI Radeon™ HD 4850 graphics card, an ATI CrossFireX Ready motherboard and one ATI CrossFireX Bridge Interconnect cable per graphics card are required
For more information, please visit the following link:
HIS IceQ 4 Cooling Technology - Pushing the HD4850 to its limit!
HIS IceQ 4 is the 4th generation of IceQ cooling technology, which is endorsed by the media worldwide. Thanks to the newly designed double-slot fans and heatsink, IceQ 4 effectively dissipate the heat from the GPU, thus enabling it for high levels of performance. The newly designed heat-pipes layout shows its strength in effectively transfer heat from the core are and reducing the GPU temperature. Larger heatsink surface areas are implemented to maximize heat dissipation. HIS IceQ 4 cool down the GPU temperature dramatically when compare with the reference cooler, allow you to maximize your overclocking potential. Cooling capacity is increased by up to 20% in gaming mode.
What's more? The ultra silent and durable fan delivers ultra-quiet and stable gaming environment for enthusiast gamer. Also the HIS IceQ 4 Fan is sensitive to ultra violet light with special UV effect.
Redefine HD Gaming
The ATI Radeon HD 4800 Series GPUs deliver a cinematic gaming experience with unprecedented performance. The powerful new TeraScale graphics will propel you deep into your gameplay with seamless frame rates and high resolutions. Enhanced anti-aliasing (AA) and anisotropic filtering create striking graphics with unparalleled realism so you can max out the settings of the most demanding next-generation games or revitalize your favorite titles. Play today while preparing for tomorrow with tessellation, support for DirectX® 10.1 and scalable ATI CrossFireXTM technology.
ATI AvivoTM HD Technology
ATI AvivoTM HD is the advanced image and video processing and display technology found in ATI RadeonTM HD GPUs and ATI TheaterTM video capture processors. Specifically designed for HDTV and HD video enthusiasts, ATI Avivo HD provides brilliant colors, sharp images, smooth playback of Blu-rayTM* and HD video content, HDMI with built-in multi-channel digital audio, and on some GPUs, Unified Video Decoding (UVD). UVD is designed to enable a cool and quiet media PC with low CPU power requirements and playback of HD 1080p content. HD Monitor is required for full 1080p enjoyment.
Native HDMI Video and Audio
A system with an ATI RadeonTM HD 4800 Series graphics card can help enhance the HD entertainment experience by providing a seamless connection to an HDTV or home theater system. With built-in 7.1 surround sound audio (AC3 / DTS ), the new GPUs and graphics cards support single cable connection directly to a compatible HDTV, projector or receiver. This single cable carries both the HD video and 8 channel audio for a clean, high definition connection. It will be equipped with an Native HDMI connector. These options give consumers more options and flexibility when connecting their PCs to monitors or home theaters for maximum enjoyment of HD content. The new GPU also supports xvYCC color which can display a wider range of color when connected to capable HDTVs.
Microsoft® DirectX® 10.1 support
ATI RadeonTM HD 4800 series GPUs offer full support for the new DirectX® 10 and DirectX® 10.1 API (Application Program Interface) from Microsoft; ready to meet the demanding needs of new, next generation games. DirectX 10 is the first totally new DirectX in the last 4 years and brings important graphics innovations that can be used by game developers for the next generation of games. DirectX 10 introduces crisp, never-beforeseen detail-rich images, visual effects and game dynamics capable of accurately simulating the real world. No matter which ATI RadeonTM HD 4800 Series GPU you choose, you can be assured that games will look as good as the developer intended!
ATI CrossFireXTM Technology
ATI CrossFireXTM multi-GPU technology takes your gaming experience to the next level with superb scalability, performance and compatibility. The technology combines the awe-inspiring capabilities of multiple ATI RadeonTM graphics cards and an ATI CrossFireX ready motherboard to meet the hard-core demands of your alternate reality. New ATI RadeonTM HD graphics cards are designed with an internal ATI CrossFireTM Bridge Interconnect system to simplify installation.
Microsoft® Windows Vista®
ATI RadeonTM HD 4800 series graphics cards provide support for the Microsoft® Windows Vista® operating system and take advantage of the Windows AeroTM graphical interface. You will be amazed by the dazzling 3D visual effects and have peace of mind that the ATI CatalystTM software and drivers are designed and thoroughly tested to ensure full compatibility and stability to help keep you up and running. All these new technologies and features make the ATI Radeon HD 4800 series of GPUs the ideal solution for ultimate HD gaming and HD video entertainment with the Windows Vista OS
