HIS HD 5770 Fan 1GB (128bit) GDDR5 PCIe (DirectX 11/ Eyefinity)
  • H577FM1GD-ALL-1600.jpg
  • SM2-31F-1-1600.jpg
  • SM2-31F-4-1600.jpg
  • H577FM1GD-Box-1600.jpg
Product Code H577FM1GD
EAN Code 4895139002980
Cooler Double-Slot Cooler
GPU 5770
Core Clock 850 MHz
Memory Clock 4.8Gbps /// MHz
Memory Size 1024 MB
Memory Type GDDR5
Memory Interface 128 bit
Interface PCI Express x16 (PCI Express 2.0)
Card Dimension 21.27X 12 X 4 cm
Availability Discontinued

  • Windows 7 Compatibility
  • AMD Vision Technology
  • ATI Premium Graphics™
  • ATI Eyefinity™
  • ATI Stream Technology™
  • ATI CrossfireX™
  • DirectX 11
  • PCI Express 2.1
  • 1080p
  • HDMI
  • HDTV
  • Dual Monitor
  • Shader Model 5
  • Unified Video Decoder 2
  • Gaming
  • Display Port
  • Native HDMI
  • DVI
  • Retail Pack
  • Special Offer
Wants more? Check out the impressive gameplay in ATI Eyefinity 6060 x 1200 resolution

HIS 5700 Key Advantage
  • DirectX® 11 - Full DirectX® 11 support enables intense gaming performance unrivalled image quality with stunning 3D visual effects, realistic lighting and lifelike imagery
  • ATI Eyefinity - Run up to 3 displays from a single graphics board and expand your gaming field of view across all displays*·
  • ATI Stream - Tap into the massiveparallel processing power of your GPU and tackle demanding tasks like video transcoding with incredible speed
  • Max Resolution: 3 x 2560x1600!!!
The Power of HIS

The Excalibur, once owned by the invincible King Arthur, denotes the leader's mighty kingship with its mystical power and fascinating beauty and brings him triumph battle after battle.

Now HIS raises this sword again for gamers.

The Legend reborn... Prepare to conquer the gaming world!

Microsoft DirectX® 11 Support

ATI RadeonTM HD 5700 Series GPUs fully support Microsoft DirectX® 11, enabling the following:

  • Tessellation is now available to PC developers for real-time rendering with ultra-realistic characters and an incredible level of detail with 3D images
  • HDR Texture compression delivers an intense level visual detail without increasing graphics memory footprint with efficiency and incredible image quality
  • Multi-threading support for DirectX® 11 accelerates rendering by leveraging all the CPU cores for overall faster gaming performance
  • DirectCompute improves PC performance by taking on some or all of a DirectX 11-enabled application's processing load, freeing up the computer's
ATI Eyefinity Technology

Run up to 3 displays from a single graphics board and expand your gaming field of view across all displays. Enjoy the ultimate immersive gaming experience with innovative "wrap around" multi-display capabilities. *

· ATI Eyefinity technology requires one panel with a DisplayPort connector to enable the third display. DisplayPort to DVI dongle is required for panel with DVI connector

Microsoft® Windows 7®

Enjoy all the benefits of Microsoft Windows 7® with ATI RadeonTM HD 5700 Series GPUs which are designed to provide an exceptional experience for the upcoming operating system.

ATI RadeonTM HD 5700 Series Key Features
  • 1GB GDDR5 memory
  • 800 Stream Processors
  • 76.8 GB/s Memory Bandwidth
  • ATI Eyefinity technology with support for up to three displays*
  • ATI Stream technology*
  • Designed for DirectCompute 11 and OpenCL
  • Accelerated Video Transcoding (AVT)*
  • Compliant with DirectX® 11 and earlier revisions
  • Supports OpenGL 3.1
  • Dual-mode ATI CrossFireXTM technology support for highly scalable performance* (up to 2 GPUs)
  • ATI AvivoTM HD video and display technology*
  • Dynamic power management with ATI PowerPlayTM technology*
  • PCI Express® 2.0 support
HIS PRODUCTS ADVANTAGE
  • HIS delivers Faster, Cooler, Quieter plus the best quality product!
  • Professional customer service and technical support
What's in the box
  • HIS Graphics Card
  • ATI CrossFireXTM Bridge Interconnect
  • Power Cable 2x 4pin in, 6 pin out
  • DVI-VGA Adapter
  • Install CD with Multilingual User Guide and BumpTop
  • Quick Installation Guide
  • HIS Power Up Label

Model Name HIS HD 5770 Fan (DirectX 11/ Eyefinity/ Full HD 1080p) Native HDMI 1GB (128bit) GDDR5 Dual Link-DVI / Display Port / HDMI (HDCP) PCIe (RoHS)
Chipset Radeon HD 5770 PCIe Series
ASIC RadeonTM HD 5770 GPU
Pixel fill rate 13.6 Gigapixels/sec
Vertex Engines TBA
Manu. Process (Micron) 40nm
Memory Size (MB) 1024
Memory Type GDDR5
Engine CLK (MHz) 850MHz
Memory CLK (Gbps) 4.8Gbps
Memory Interface (bit) 128
Power Supply Requirement 450 Watt or greater power supply with one 75W 6-pin PCI Express® power connectors recommended (600 Watt and two 6-pin connectors for ATI CrossFireXTM technology in dual mode)
Max. Resolution 3x 2560*1600 (Dual dual-link)
Bus Interface PCI Express x16
Display Port
Yes
HDMI Yes
DVI Yes
2nd DVI No

ATI Radeon™ HD 5770 System Requirements
  • PCI Express® based PC is required with one X16 lane graphics slot available on the motherboard
  • 450 Watt or greater power supply with one 75W 6-pin PCI Express® power connectors recommended (600 Watt and two 6-pin connectors for ATI CrossFireXTM technology in dual mode)
  • Certified power supplies are recommended. Refer to http://ati.amd.com/certifiedPSU for a list of Certified products
  • Minimum 1GB of system memory
  • Installation software requires CD-ROM drive
  • DVD playback requires DVD drive
  • Blu-ray playback requires Blu-ray drive
  • For an ATI CrossFireXTM system, a second ATI RadeonTM HD 5770 graphics card, an ATI CrossFireX Ready motherboard and one ATI CrossFireX Bridge Interconnect cable per graphics card are required
Expand, Accelerate, Dominate

Now, more people than ever can experience real innovation in DirectX® 11 gaming with ATI RadeonTM HD 5700 Series graphics processors. Loaded with advanced technology, these GPUs have the power and premium features you need for fully immersive gameplay. Expand your visual real estate across up to three displays and get lost in the action with revolutionary ATI Eyefinity Technology. Using ATI Stream technology, accelerate even the most demanding applications and do more than ever with your PC. The first GPUs in this class to offer full support for DirectX 11, these GPUs enable rich, realistic visuals and explosive HD gaming performance so you can dominate the competition.

  • Get unrivalled visual quality and intense gaming performance and for today and tomorrow with support for Microsoft® DirectX® 11
  • With ATI Eyefinity technology get the ultimate immersive gaming experience innovative ‘wrap around' multi-display capabilities
  • Tap into the massive parallel processing power of your GPU with ATI Stream technology and tackle demanding tasks like video transcoding with incredible speed
  • Experience the speed, responsiveness and performance of ultra-high bandwidth GDDR5 memory
  • ATI CrossFireXTM technology in dual-mode offers advanced scalability
ATI Eyefinity Technology

Run up to 3 displays from a single graphics board and expand your gaming field of view across all displays. Enjoy the ultimate immersive gaming experience with innovative "wrap around" multi-display capabilities. *

  • ATI Eyefinity technology requires one panel with a DisplayPort connector to enable the third display. DisplayPort to DVI dongle is required for panel with DVI connector
  • Driver version 8.66 (Catalyst 9.10) or above is required to support ATI Eyefinity technology.
  • ATI Eyefinity technology works with games that support non-standard aspect ratios, which is required for panning across three displays.
Microsoft DirectX® 11 Support

ATI RadeonTM HD 5700 Series GPUs fully support Microsoft DirectX® 11, enabling the following:

  • Tessellation is now available to PC developers for real-time rendering with ultra-realistic characters and an incredible level of detail with 3D images
  • HDR Texture compression delivers an intense level visual detail without increasing graphics memory footprint with efficiency and incredible image quality
  • Multi-threading support for DirectX® 11 accelerates rendering by leveraging all the CPU cores for overall faster gaming performance
  • DirectCompute improves PC performance by taking on some or all of a DirectX 11-enabled application's processing load, freeing up the computer's
ATI Stream Technology

Thanks to the ATI Stream Technology, developers can now leverage AMD GPUs and CPUs for enhanced application performance and user experience. The massively parallel, programmable GPU architecture delivers dramatic performance and power efficiency

ATI Stream technology is a set of advanced hardware and software technologies that enable AMD graphics processors (GPU), working in concert with the system's central processor (CPU), to accelerate many applications beyond just graphics. This enables better-balanced platforms capable of running demanding computing tasks faster than ever.

Along with leading third party industry partners and academic institutions worldwide, AMD is building a complete ATI Stream computing ecosystem, one that delivers the performance, applications, software and tools necessary to turn AMD's low-cost application acceleration vision into reality.

ATI AvivoTM Technology Enhanced Unified Video Decoder 2 (UVD 2)

Watch the hottest Blu-ray movies or other HD content at full 1080p display resolution and beyond and enjoy a more feature rich experience with enhanced Unified Video
Decoder 2 (UVD 2):

  • Enhanced UVD 2 now support hardware acceleration decode of dual 1080p HD video streams
  • Brighter Whites processing increases the blue value of white colors for brighter and more vivid video playback
  • Independent Video Gamma Control allows you to set video gamma independently from Windows desktop for a better viewing experience
  • Dynamic Video Range Control enables user to control levels of black and white during playback
Microsoft® Windows 7®

Enjoy all the benefits of Microsoft Windows 7® with ATI RadeonTM HD 5700 Series GPUs which are designed to provide an exceptional experience for the upcoming operating system.

HIS Radeon graphics chips and Windows 7 graphics driver draws Windows incredibly efficiently - helping to save system memory and enable a superior Windows experience. The Windows 7 Aero desktop was designed using the DirectX 11 API, for which ATI 5700 Series of products provide full support. Besides, they fully supports the new Direct2D API - enabling enhanced 2D graphics features, and anti-aliased text to make applications running under the Windows 7 desktop look amazingly smooth and readable.

ATI CrossFireXTM Technology

- "Take gaming to a new level with plug-n-play ease"

Get up to 1.8X of a graphics performance boost with ATI CrossFireXTM technology in dual mode.

Experience stunning visual realism in today's demanding games with uncompromising image quality, especially on HD displays. ATI CrossFireX: Multiply and Conquer!
