HIS 7870 IceQ 2GB GDDR5 PCI-E DVI/HDMI/2xMini DP
  • H787Q2G2M_all_1600.jpg
  • 0163_01_1600.jpg
  • 0163_02_1600.jpg
  • H787Q2G2M_08_1600.jpg
  • 0163_04_1600.jpg
  • 0163_05_1600.jpg
  • 0163_06_1600.jpg
  • 0163_07_1600.jpg
  • 0131_07_1600.jpg
  • H787Q2G2M_3D_BOX_1600.jpg
Product Code H787Q2G2M
EAN Code 4895139007015
Cooler IceQ
GPU 7870
Core Clock 1000 MHz
Memory Clock 4800 MHz
Memory Size 2048 MB
Memory Type GDDR5
Memory Interface 256 bit
Interface PCI Express 3.0 x16
Card Dimension 14 x 4.4 x 29.7 cm
Box Dimension 22 x 11.3 x 39 cm
Availability

  • Windows 7 Compatibility
  • AMD Radeon Graphics
  • AMD Vision Technology
  • AMD HD3D Technology
  • AMD Eyefinity Technology
  • DirectX 11
  • IceQ
  • PCI Express 3.0
  • OpenGL 4.2
  • 1080p
  • HDMI
  • HDTV
  • Dual Monitor
  • Shader Model 5
  • Gaming
  • Mini DisplayPort
  • Native HDMI
  • DVI
  • Retail Pack
IceQ– Cooler, Quieter.

Crossfire Advantage
IceQ ensures effective cooling when there is another card in front blocking the fan inlet, such as in CrossFire setup.

By expelling the hot air, IceQ removes all the heat generated by the GPU out of the computer chassis, prevents the hot air from accumulating inside and enhancing the overall stability. The more crowded the chassis, the greater will be the impact.

The demonstration shows that the IceQ does outperform the 3rd party cooler in closed environment. Cool air is drawn from both sides of the fan and hot air is forced out of the computer case. This ensures effective cooling when there is another card in front blocking the fan inlet, such as in CrossFire setup."

Black Hole Impeller
Black hole impeller ensures large amount of cool air is ready. It draws cool air from both sides of the fan even there is another card blocking the fan inlet on the front side of fan.

Cooler
With IceQ, the card is up to 25 °C cooler than the reference cooler.

The super large 80 x 21.5mm single blower fan draws massive amount of cool air to cool the GPU directly.

The fan is extremely durable with a life span of up to 50,000 hours!

4 wide heatpipes optimize cooling performance by removing heat from the core area.

The extra large 35 x 30mm copper heatsink provides a large heat dissipation area.

The card also features fan control and fan monitoring, you are able to read fan speed & Asic temperature from CCC or software.

Quieter
IceQ is one of the quietest coolers. The card is below 28dB when watching movies, surfing Facebook, working. The card is quiet in 2D mode and remains quiet whether you are gaming, online socializing, entertaining or working.

The card is up to 6dB quieter than the reference cooler.

High Quality Components

HIS uses only the finest materials and the most advanced techniques to build our cards, making them one of the most stable and durable product in the industry.

CrossFireX Ready!
The card's is armed with Crossfire Connector, ready for 2-way CrossFire & multiplied performance!

OC Equipment
OC material is ready for Overclocking to the limit! HIS cards utilize Dynamic Phase Control PWM IC to save power for better use. Along with digital power design, 2 ounces Copper Layer, HIS cards make the best out of power, allowing users to clock speeds to the full potential!

Safety Design
HIS cards are engineered with the highest standard of safety, preventing them any potential damages. Solid State Choke stabilizes the card and Full Solid State Capacitors enhances the card’s stability in critical gaming situations!

Stronger, Last Longer!
HIS special metal rib further strengthens the PCBs, making the cards extra stable and durable. You can count on HIS cards to game hard for 24/7/365 for years!

New Design, New Experiences

PCI-e 3.0 Support
Armed with the latest PCI-e 3.0 bus design maximizes performance by delivering double bandwidth per lane of PCI-e 2.x. Paired the card with the latest platforms and get the ultimate performance!

More Graphics, Less Power

Optimized Power & Performance
The new architecture of the card gets more usable processing power for your money, enabling better frame rates in the latest games at high resolutions. In addition, with AMD PowerPlay™ &  AMD PowerTune technologies, you can optimize the balance between performance and power consumption of your system by adjusting the engine clock during runtime of the card. Manage the power and keep your wallet loaded!

See More, Win More!

The card is capable to turn your computer into a super gaming machine. Enjoy the latest 3D games with stunning graphics and effects that your enemies cannot match! Get an immersive experience with AMD Eyefinity “2.0”!

Expand your game across up to 4 displays while your opponents have one monitor. Along with all-new support for stereo 3D, universal bezel compensation and brand new display configurations, take the unfair advantage over your opponent and win more with the surround sight

Game Better & Faster

Game Better & Faster
With full Microsoft DirectX® 11.1 support, the card is ready for next generation DirectX games. Equipped with AMD HD3D technology, you can enjoy a stereo 3D experience in the latest 3D games. The card also offers up to 2x faster tessellation and faster DirectCompute over earlier cards. Gamers will be pleased to enjoy the life-like graphics!

Sounds Better
Output protected high bit rate 7.1 channel surround sound over HDMI with no additional cables required, heightening the sense of reality!

See Better, Enjoy Better!

The card supports 30” LCD monitor and any large size TV up to 80" feature with 16:9 ratio in amazing 4096 by 2160 resolution. Up-scaling your computer into a multimedia center with the biggest display!

Enjoy HD Beauty
With Full HD 1080p support, the card delivers high quality 1920X1080 graphics, enabling seamless full-screen video playback. See HD, hear HD and feel HD - Enjoy the beautiful graphics now with the card!

Enjoy Copy Protected Movies
The card is HDCP complaint, enabling users to play copy-protected content, such as commercial DVD movies.

Enjoy True to Life Graphics
Quad HD videos have resolution four times that of current HD videos, meaning images too clear that may deceive your eyes! With the card, you are set for getting the movie theater experience to your home. You may be able to watch a video shooting the Eiffel tower and zoom it in to see your friend’s face clearly from the top! Get your eyes impressed and enjoy mind-blowing graphics with extreme clarity, depth and texture!

View More, Work Better

Having one dedicated screen just for twitter or Facebook and a second for outlook is not a dream anymore. The card features 2 Mini-display Ports for enhanced workspace flexibility. You can easily connect to two displays, including the 27” Apple LED Cinema Displays with the two Mini DisplayPorts. The dual-link DVI port allows you connect to a 30” DVI display up to 2560x1600. Resolution can even reach 4096x2160 with HDMI®  that are good for TV up to 80"!

The card is an ideal solution for all those who rely on having several applications visible simultaneously for extra productivity. Multi-tasking just got a lot simpler! Make your computer a multi-display workstation!

HIS Products Advantage
  • HIS delivers Faster, Cooler, Quieter plus the best quality product!
  • Professional customer service and technical support
What's in the box
  • HIS Graphics Card
  • CrossFireXTM Bridge
  • DVI-VGA Adapter
  • Install CD with Multilingual User Guide
  • Quick Installation Guide
  • HIS Power Up Label

Model Name HIS 7870 IceQ 2GB GDDR5 PCI-E DVI/HDMI/2xMini DP
Chipset Radeon HD 7870 PCIe Series
ASIC RadeonTM HD 7870 GPU
Manu. Process (Micron) 28nm
Memory Size (MB) 2048
Memory Type GDDR5
Engine CLK (MHz) 1000MHz
Memory CLK (Gbps) 4.8Gbps
Memory Interface (bit) 256bit
Power Supply Requirement 500 Watt or greater power
Max. Resolution 4096x2160 per display (DisplayPort 1.2)
2560x1600 per display (Dual-link DVI)
2048x1536 per display (VGA)
Bus Interface PCI Express 3.0 x16
Mini Display Port Yes
HDMI Yes
DVI Dual-link DVI-I
VGA No

HD 7870 System Requirement

  • PCI Express® based PC is required with one X16 lane graphics slot available on the motherboard
  • 500W (or greater) power supply with two 75W 6-pin PCI Express® power connectors recommended
  • Certified power supplies are recommended. Refer to http://support.amd.com/us/certified/power-supplies/Pages/listing.aspx for a list of Certified products
  • Minimum 1GB of system memory
  • Installation software requires CD-ROM drive
  • DVD playback requires DVD drive
  • Blu-ray™ playback requires Blu-ray drive
  • The operation of AMD CrossFire™ technology in dual mode requires a second AMD Radeon™ HD 7800 Series graphics card and an AMD CrossFire™ Ready motherboard
