HIS 7850 IceQ 2GB GDDR5 PCI-E DVI/HDMI/2xMini DP (iPower)
  • H785Q2G2M_all_1600.jpg
  • H785Q2G2M_01_1600[1].jpg
  • H785Q2G2M_04_1600[2].jpg
  • H787QT2G2M_06_1600[1][1].jpg
  • H787QT2G2M_07_1600[1][1].jpg
  • 0131_07_1600[2][1].jpg
  • H785Q2G2M_3D_BOX_1600.jpg
Product Code H785Q2G2M
EAN Code 4895139007787
Cooler IceQ
GPU 7850
Core Clock 860 MHz
Memory Clock 4800 MHz
Memory Size 2048 MB
Memory Type GDDR5
Memory Interface 256 bit
Interface PCI Express 3.0 x16
Card Dimension 29.7 x 14 x 4.4 cm
Box Dimension 39 x 22 x 11.3 cm
Availability

  • iPower
  • Windows 7 Compatibility
  • AMD Radeon Graphics
  • AMD Vision Technology
  • AMD HD3D Technology
  • AMD Eyefinity Technology
  • DirectX 11
  • IceQ
  • PCI Express 3.0
  • OpenGL 4.2
  • OpenCL 1.2
  • 1080p
  • HDMI
  • HDTV
  • Dual Monitor
  • Shader Model 5
  • Unified Video Decoder
  • 7.1 Channel Audio
  • Gaming
  • Mini DisplayPort
  • Native HDMI
  • DVI
  • Retail Pack
iPower: More Voltage, More Overclocking!

Improved Power Supply Input
Increased Power supply input for more voltage for overclocking!

HIS 7850 IceQ AMD 7850 Ref Board
Power Input 6+6 6
PWM Phase 5+1+1+1=8 4+1+1+1=7
Copper Layer 2Oz 1Oz

 IceQ– Cooler, Quieter

Crossfire Advantage
IceQ ensures effective cooling when there is another card in front blocking the fan inlet, such as in CrossFire setup.

By expelling the hot air, IceQ removes all the heat generated by the GPU out of the computer chassis, prevents the hot air from accumulating inside and enhancing the overall stability. The more crowded the chassis, the greater will be the impact.




The demonstration shows that the IceQ does outperform the 3rd party cooler in closed environment. Cool air is drawn from both sides of the fan and hot air is forced out of the computer case. This ensures effective cooling when there is another card in front blocking the fan inlet, such as in CrossFire setup.

Black Hole Impeller
Black hole impeller ensures large amount of cool air is ready. It draws cool air from both sides of the fan even there is another card blocking the fan inlet on the front side of fan.

Cooler
The super large 57mm single blower fan draws massive amount of cool air to cool the GPU directly.

The fan is extremely durable with a life span of up to 50,000 hours!

2x 6mm plus 2x 8mm wide heatpipes optimize cooling performance by removing heat from the core area.

The extra large 115 x 94mm copper heatbase provides a 140 x 125mm large heat dissipation area.

The card also features fan control and fan monitoring, you are able to read fan speed & Asic temperature from CCC or software.

Quieter
IceQ is one of the quietest coolers, making the card 8dB quieter than the reference cooler. The card is below 28dB when watching movies, surfing Facebook, working. The card remains quiet whether you are gaming, online socializing, entertaining or working.

High Quality Component

OC Equipment

The card is equipped with improved power design which is great for OC! HIS cards utilize Dynamic Phase Control PWM IC to save power for better use. Along with improved power design, digital power design, 2 ounces Copper Layer, HIS cards make the best out of power, carrying better OC capability and pushing clock speeds to the full potential!

CrossFireX Ready
The card's is armed with Crossfire Connector, ready for CrossFire & multiplied performance!

Safer, Last Longer

Enhances stability in critical gaming situations!
HIS cards are engineered with the highest standard of safety, preventing them any potential damages. Solid State Choke stabilizes the card and Full Solid State Capacitors ensures the best power quality and enhances the card’s stability in critical gaming situations!

Special Metal Rib
PCB might easily warped due to prolonged hanging on motherboard & casing, potentially causing cracks on BGA solder joints and resulting in malfunctioning of the card. The HIS special metal rib provides extra strength to the PCBs to avoid warpage, making the cards extra stable and durable. You can count on HIS cards to game hard for 24/7/365 for years!

iTurbo – Your Graphics Card’s Assistant

iTurbo is your graphics card’s assistant to control your card to be quiet, cool. Experience overclocking by simply pressing the iTurbo Button!

User Friendly Overclocking Software: Cooler, Quieter, OC!
iTurbo's Fan Control and Fan Monitoring allow easy adjustment of your card to its maximum cooling performance or to run your card quietly!

Press iTurbo: OC Right Away!
With the smart auto overclocking function, users can experience a slight performance boost for selected HIS graphic cards with just one click!

Powerful Overclocking Software
Either you wish to unleash its full potential or to make it more environmental friendly, iTurbo is ready for you!

iTurbo is compatible with all cards! Enjoy OC no matter what card you have!

Model Name HIS 7850 IceQ 2GB GDDR5 PCI-E DVI/HDMI/2xMini DP
Chipset Radeon HD 7850 PCIe Series
ASIC RadeonTM HD 7850 GPU
Manu. Process (Micron) 28nm
Memory Size (MB) 2048
Memory Type GDDR5
Engine CLK (MHz) 860MHz
Memory CLK (Gbps) 4.8Gbps
Memory Interface (bit) 256bit
Power Supply Requirement 500 Watt or greater power
Max. Resolution 4096x2160 per display (DisplayPort 1.2)
2560x1600 per display (Dual-link DVI)
2048x1536 per display (VGA)
Bus Interface PCI Express 3.0 x16
Mini Display Port Yes
HDMI Yes
DVI Dual-link DVI-I
VGA No

HD 7850 System Requirement

  • PCI Express® based PC is required with one X16 lane graphics slot available on the motherboard
  • 500W (or greater) power supply with two 75W 6-pin PCI Express® power connectors recommended
  • Certified power supplies are recommended. Refer to http://support.amd.com/us/certified/power-supplies/Pages/listing.aspx for a list of Certified products
  • Minimum 1GB of system memory
  • Installation software requires CD-ROM drive
  • DVD playback requires DVD drive
  • Blu-ray™ playback requires Blu-ray drive
  • The operation of AMD CrossFire™ technology in dual mode requires a second AMD Radeon™ HD 7800 Series graphics card and an AMD CrossFire™ Ready motherboard
