HIS 7950 IceQ Boost Clock 3GB GDDR5 PCI-E DVI/HDMI/2xMini DP
  • H795QC3G2M_all_1600.jpg
  • 0137_01_1600[1].jpg
  • 0137_02_1600[1].jpg
  • 0137_04_1600[1].jpg
  • 0137_06_1600[1].jpg
  • 0137_08_1600[2].jpg
  • 0137_07_1600[1].jpg
  • H795QC3G2M_3D_BOX_1600.jpg
Product Code H795QC3G2M
EAN Code 4895139008005
Cooler IceQ
GPU 7950
Core Clock 850 (Boost Clock 925) MHz
Memory Clock 5000 MHz
Memory Size 3072 MB
Memory Type GDDR5
Memory Interface 384 bit
Interface PCI Express 3.0 x16
Card Dimension 15.5 x 5.8 x 29.5 cm
Box Dimension 22 x 11.3 x 39 cm
Availability

  • Windows 7 Compatibility
  • AMD Radeon Graphics
  • AMD Vision Technology
  • AMD HD3D Technology
  • AMD Eyefinity Technology
  • DirectX 11
  • IceQ
  • PCI Express 3.0
  • OpenGL 4.2
  • OpenCL 1.2
  • 1080p
  • HDMI
  • HDTV
  • Dual Monitor
  • Shader Model 5
  • Unified Video Decoder
  • 7.1 Channel Audio
  • Gaming
  • Mini DisplayPort
  • Native HDMI
  • DVI
  • Retail Pack

HIS 7950 IceQ Boost Clock features Boost Clock is Faster, IceQ, is Cooler & Quieter, iTurbo and Long Lasting Design!

Boost Clock is Faster!

The card has the latest Boost Clock technology, providing extra performance for the most demanding games and applications!



HIS 7950 IceQ Boost Clock AMD 7950 Ref. Board
Core Clock 850 MHz 800 MHz
Boost Clock 925 MHz N.A





IceQ– Cooler, Quieter

Crossfire Advantage
IceQ ensures effective cooling when there is another card in front blocking the fan inlet, such as in CrossFire setup. By expelling the hot air, IceQ removes all the heat generated by the GPU out of the computer chassis, prevents the hot air from accumulating inside and enhancing the overall stability. The more crowded the chassis, the greater will be the impact.


The demonstration shows that the IceQ does outperform the 3rd party cooler in closed environment. Cool air is drawn from both sides of the fan and hot air is forced out of the computer case. This ensures effective cooling when there is another card in front blocking the fan inlet, such as in CrossFire setup.



Black Hole Impeller
Black hole impeller ensures large amount of cool air is ready. It draws cool air from both sides of the fan even there is another card blocking the fan inlet on the front side of fan.

Cooler
With IceQ, the card is up to 12 °C cooler than the Reference Cooler.

Quieter
IceQ is one of the quietest coolers. The card is below 28dB when watching movies, surfing Facebook, working. The card remains quiet whether you are gaming, online socializing or entertaining.

Fan Design
The super large 57mm single blower fan draws massive amount of cool air to cool the GPU directly.

The fan is extremely durable with a life span of up to 50,000 hours!

2x 6mm plus 2x 8mm wide heatpipes optimize cooling performance by removing heat from the core area.

The extra large 115 x 94mm copper heatbase provides a 140 x 125mm large heat dissipation area.

The card also features fan control and fan monitoring, you are able to read fan speed & Asic temperature from CCC or software.



iTurbo – Your Graphics Card’s Assistant

iTurbo is your graphics card’s assistant to control your card to be quiet, cool. Experience overclocking by simply pressing the iTurbo Button!

User Friendly Overclocking Software: Cooler, Quieter, OC!
iTurbo's Fan Control and Fan Monitoring allow easy adjustment of your card to its maximum cooling performance or to run your card quietly!

Press iTurbo: OC Right Away!
With the smart auto overclocking function, users can experience a slight performance boost for selected HIS graphic cards with just one click!

Powerful Overclocking Software
Either you wish to unleash its full potential or to make it more environmental friendly, iTurbo is ready for you!

iTurbo is compatible with all cards! Enjoy OC no matter what card you have!

Long Lasting Design: Safer, Last Longer!

Dual Bios
The card has two bios, ensuring the card runs properly. You can always switch to the second Bios if the card does not run with the first Bios.

Enhances stability in critical gaming situations!
HIS cards are engineered with the highest standard of safety, preventing them any potential damages. Solid State Choke stabilizes the card and Full Solid State Capacitors ensures the best power quality and enhances the card’s stability in critical gaming situations!

Special Metal Rib
PCB might easily warped due to prolonged hanging on motherboard & casing, potentially causing cracks on BGA solder joints and resulting in malfunctioning of the card. The HIS special metal rib provides extra strength to the PCBs to avoid warpage, making the cards extra stable and durable. You can count on HIS cards to game hard for 24/7/365 for years!

OC Equipment

The card is equipped with improved power design which is great for OC! HIS cards utilize Dynamic Phase Control PWM IC to save power for better use. Along with improved power design, digital power design, 2 ounces Copper Layer, HIS cards make the best out of power, carrying better OC capability and pushing clock speeds to the full potential!

Built for Crossfire

CrossFireX Ready!
The card's is armed with 2x Crossfire Connectors, ready for 4x CrossFire & strengthened performance!

New Technology, New Experiences

GCN

With AMD GCN technology, the card optimizes DirectX® 11.1 gaming performance automatically up to 2.5 times faster! It also offers up to 4.5x compute performance and up to 95% lower GPU Idle Power Consumption!

Apps Faster & Smoother!

The card enables a “quality graphics” experience on everyday applications, giving huge performance boosts on image processing, file compression, media converter apps, and a lot more!
• Adobe Photoshop CS6
• Corel Winzip 16.5
• Musemage
• Handbrake
• MotionDSP Vreveal
• GIMP
• Cyberlink Power Director
• ArcSoft Media Converter

PCI-e 3.0 Support

Armed with the latest PCI-e 3.0 bus design maximizes performance by delivering double bandwidth per lane of PCI-e 2.x. Paired the card with the latest platforms and get the ultimate performance!

More Graphics, Less Power!

The new architecture of the card gets more usable processing power for your money, enabling better frame rates in the latest games at high resolutions.  In addition, with AMD ZeroCore Power & AMD PowerTune technologies, you can optimize the balance between performance and power consumption of your system by adjusting the engine clock during runtime of the card. Manage the power and keep your wallet loaded!

See More, Enjoy More!

The card supports 30” LCD monitor and any large size TV up to 80" feature with 16:9 ratio in amazing 4096 by 2160 resolution. Up-scaling your computer into a multimedia center with the biggest display!


Enjoy HD Beauty
With Full HD 1080p support, the card delivers high quality 1920X1080 graphics, enabling seamless full-screen video playback. See HD, hear HD and feel HD - Enjoy the beautiful graphics now with the card!


Enjoy Copy Protected Movies
The card is HDCP complaint, enabling users to play copy-protected content, such as commercial DVD movies.


Enjoy True to Life Graphics
Quad HD videos have resolution four times that of current HD videos, meaning images too clear that may deceive your eyes! With the card, you are set for getting the movie theater experience to your home. You may be able to watch a video shooting the Eiffel tower and zoom it in to see your friend’s face clearly from the top! Get your eyes impressed and enjoy mind-blowing graphics with extreme clarity, depth and texture!


See more, Win More!
The card is capable to turn your computer into a super gaming machine. Enjoy the latest 3D games with stunning graphics and effects that your enemies cannot match! Get an immersive experience with AMD Eyefinity “2.0”!

Expand your game across up to 4 displays while your opponents have one monitor. Along with all-new support for stereo 3D, universal bezel compensation and brand new display configurations, take the unfair advantage over your opponent and win more with the surround sight

View More, Work Better

Having one dedicated screen just for twitter or Facebook and a second for outlook is not a dream anymore. The card features 2 Mini-display Ports for enhanced workspace flexibility. You can easily connect to two displays, including the 27” Apple LED Cinema Displays with the two Mini DisplayPorts. The dual-link DVI port allows you connect to a 30” DVI display up to 2560x1600. Resolution can even reach 4096x2160 with HDMI® , good for TV up to 80"!

Hear Better in Video Conference
Most GPUs today support only one audio stream at a time. The card, however, has Discrete Digital Multi-Point Audio that can simultaneously output multiple, independent audio streams. Audio seamlessly follows the video, providing affordable multi-display, multi-audio conferencing for consumers!

The card is an ideal solution for all those who rely on having several applications visible simultaneously for extra productivity. Multi-tasking just got a lot simpler! Make your computer a multi-display workstation!

Disclaimer:
The figures of current outputs are estimated from PWM phase specifications. The maximum current output can be different with a different setting.

The figures of 3Dmark 11 above are based on test results in HIS lab with the following platform:
• Motherboard Chipset: AMD 890FX
• System Memory Size: DDR3 4G
• CPU Type And Speed: Athlon II X4 635 2.9GHz AM3
• Operation System: Windows 7 64bits
• Background Resolution: 1024x768x32bit
• Background Rresh Rate: 75Hz
Results may vary based upon system setting.

HIS Products Advantage
  • HIS delivers Faster, Cooler, Quieter plus the best quality product!
  • Professional customer service and technical support
What's in the box
  • HIS Graphics Card
  • CrossFireXTM Bridge
  • DVI-VGA Adapter
  • Install CD with Multilingual User Guide
  • Quick Installation Guide
  • HIS Power Up Label



Model Name HIS 7950 IceQ Boost Clock 3GB GDDR5 PCI-E DVI/HDMI/2xMini DP
Chipset Radeon HD 7950 PCIe Series
ASIC RadeonTM HD 7950 GPU
Manu. Process (Micron) 28nm
Memory Size (MB) 3072
Memory Type GDDR5
Engine CLK (MHz) 850MHz (Boost Clock 925MHz)
Memory CLK (Gbps) 5Gbps
Memory Interface (bit) 384bit
Power Supply Requirement 500 Watt or greater power
Max. Resolution 4096x2160 per display (DisplayPort 1.2)
2560x1600 per display (Dual-link DVI)
2048x1536 per display (VGA)
Bus Interface PCI Express 3.0 x16
Mini Display Port Yes
HDMI Yes
DVI Dual-link DVI-I
VGA No



HD 7950 System Requirement

  • PCI Express® based PC is required with one X16 lane graphics slot with 2 slots space available on the motherboard
  • 500W (or greater) power supply with two 75W 6-pin PCI Express power connectors recommended
  • Certified power supplies are recommended. Refer to http://support.amd.com/us/certified/power-supplies/Pages/listing.aspx for a list of Certified products
  • Minimum 1GB of system memory
  • Installation software requires CD-ROM drive
  • DVD playback requires DVD drive
  • Blu-ray™ playback requires Blu-ray drive
  • The operation of AMD CrossFire™ technology in dual mode requires a second AMD Radeon™ HD 7950 graphics card and an AMD CrossFire™ Ready motherboard.
